EBG resistors are found in numerous power electronics applications:
- Frequency converters (e.g. in wind power plants)
- Drives of large electric engines
- High-voltage and medium-voltage grids (e.g. high-voltage direct current transmission - HVDC)
- Drives for trains and electric vehicles
- Medical technolgy (x-ray, MRI, CT, PET scan machines)

Our range of products include non-inductive thick film high-voltage, high-power and precision resistors as well as custom-designed resistors. Our resistors are available in different designs, sizes, ohmic values and tight tolerances.

ON-LINE CATALOG

Power Resistors

up to 600W

Series LXP-18 TO-220_ 18 W
Series LXP-20 TO-220_ 20 W
Series LXP-100 B TO-247_ 100 W
Series MXP 35 TO-220_35 W
Series MSP 35 SMD TO-220_35 W
Series AXP-50_50 W
Series AXP-100 B_100 W
Series AXM_100 W
Series GXP 120, SOT-227_120 W
Series HPP 150_150 W
Series VHP_180 W
Series HPS 150_150 W
Series HXP 200, SOT-227_200 W
Series HXP-600_600 W

Series LXP-18 TO-220

18 W Thick Film Power Resistors for high-frequency and pulse-loading applications. Single screw mounting.

Features

18 W operating power
TO-220 package configuration
Tolerance range ±0.5 % to ±10 %
Ohmic range 0.05 Ω to 1 MΩ (higher values on request)
Temperature coefficient ±50 ppm/°C for ≥ 10 Ω
Non-Inductive design
ROHS conform

Typical applications

Power supplies
Motor Drives & Controls
Electric Vehicle
Converters
Medical
Instrumentation
Traction
Welding

Downloads

Product Data Sheet LXP-18 TO-220

Series LXP-20 TO-220

20 W Thick Film Power Resistors for high-frequency and pulse-loading applications. No mounting hole (snap-on). Heat sink required.

Features

20 W operating power
TO-220 package configuration
Tolerance range ±0.5 % to ±10 %
Ohmic range 0.05 Ω to 1 MΩ (higher values on request)
Temperature coefficient ±50 ppm/°C for ≥ 10 Ω
Non-Inductive design
ROHS conform

Typical applications

Power supplies
Motor Drives & Controls
Electric Vehicle
Converters
Medical
Instrumentation
Traction
Welding

Downloads

Product Data Sheet LXP-20 TO-220

Series LXP-100 B TO-247

100 W Thick Film Power Resistors for high-frequency and pulse-loading applications. Version B for enforced mechanical stability.

Features

100 W operating power
TO-247 package configuration
Tolerance range ±1 % to ±10 %
Ohmic range 0.05 Ω to 1 MΩ (higher value on request)
Temperature coefficient ±50 ppm/°C for ≥ 10 Ω (lower TCR on request)
Non-Inductive design
ROHS conform
AEC-Q200 qualified

Typical applications

Power supplies
Motor Drives & Controls
Electric Vehicle
Converters
Medical
Instrumentation
Traction
Welding

Downloads

Product Data Sheet LXP-100 B TO-247

Series MXP 35 TO-220

35 W Thick Film Power Resistors for high-frequency and pulse-loading applications. Single screw mounting.

Features

35 W operating power
TO-220 package configuration
Tolerance range ±0.5 % to ±10 %
Ohmic range 0.05 Ω to 1 MΩ (other values on request)
Temperature coefficient ±50 ppm/°C for ≥ 10 Ω
Non-Inductive design
ROHS conform

Typical applications

Power supplies
Motor Drives & Controls
Electric Vehicle
Converters
Medical
Instrumentation
Traction
Welding

Downloads

Product Data Sheet MXP 35 TO-220

MSP-35 SMD-TO-220, MHP-35 Power Resistor

Series MSP 35 SMD TO-220

35 W Thick Film Power Resistors for surface mount including metal tab. MHP 35 for high temperature soldering!

Features

35 W operating power
SMD TO-220 package configuration
Tolerance range ±0.5 % to ±10 %
Ohmic range 0.1 Ω to 1 MΩ (other values on request)
Temperature coefficient ±50 ppm/°C for ≥ 10 Ω
Non-Inductive design
ROHS conform

Typical applications

Power supplies
Motor Drives & Controls
Electric Vehicle
Converters
Medical
Instrumentation
Traction
Welding

Downloads

Product Data Sheet MSP 35 SMD TO-220

Series AXP-50

50 W resistors with up to 4 wire terminals.

Features

1 x 50 W / 2 x 20 W / 3 x 10W operating power
Tolerance range ±1 % to ±10 %
Ohmic range 1 Ω to 1 MΩ
Temperature coefficient ±50 ppm/°C to ±250 ppm/°C
Standard wire length 100mm (other lengths available)
Non-Inductive design
ROHS conform

Typical applications

Motor Drives & Controls
Power Supplies
Control Devices
Telecommunications
Robotics
Medical
Regen Energy
Traction
Welding
Electric Vehicle

Downloads

Product Data Sheet AXP-50

Series AXP-100 B

100 W resistors with 4 wire terminals, Version B for enforced mechanical stability.

Features

1 x 100 W / 2 x 38 W / 3 x 17 W operating power
Tolerance range ±1 % to ±10 %
Ohmic range 1 Ω to 1 MΩ
Temperature coefficient ±50 ppm/°C to ±250 ppm/°C
Standard wire length 100mm (other lengths available)
Non-Inductive design
ROHS conform

Typical applications

Motor Drives & Controls
Power Supplies
Control Devices
Telecommunications
Robotics
Medical
Regen Energy
Traction
Welding
Electric Vehicle

Downloads

Product Data Sheet AXP-100 B

Series AXM

100 W low ohm pulse power resistor - only configuration 1 possible

Features

100 W operating power
Tolerance range ±5 % to ±10 %
Ohmic range 0.05 Ω to 0.5 Ω
Temperature coefficient ±500 ppm/°C
Standard wire length 10mm (other lengths available)
Non-Inductive design
ROHS conform

Typical applications

Motor Drives & Controls
Welding
Traction
Medical
Electric Vehicle
Frequency Converters

Downloads

Product Data Sheet AXM

Series GXP 120 SOT-227 Housing

120 W power resistor in "ISOTOP" power device. 6 different layouts available. Mounting to heat sink is required.

Features

1 x 120 W / 2 x 50 W / 3 x 30 W operating power
Tolerance range ±1 % to ±10 %
Ohmic range 0.1 Ω to 1 MΩ
Temperature coefficient > 1R ±250 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
AEC-Q200 compliant

Typical applications

Motor Drives & Controls
Power Supplies
Control Devices
Telecommunications
Robotics
Medical
Regen Energy
Traction
Welding
Electric Vehicle

Downloads

Product Data Sheet GXP 120 SOT-227 Housing

Series HPP 150

150 W power resistor according to VDE 0160 and UL 94-V0. 4 different layouts available. Easy mounting to heat sink.

Features

1 x 150 W / 2 x 60 W / 3 x 33 W operating power
Tolerance range ±1 % to ±10 %
Ohmic range 1 Ω to 1M Ω (other values on request)
Temperature coefficient ±250 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Motor Drives & Controls
Power Supplies
Control Devices
Telecommunications
Robotics
Medical
Regen Energy
Traction
Welding
Electric Vehicle

Downloads

Product Data Sheet HPP 150

Series VHP

180 W power resistor according to VDE 0160 and UL 94-V0. 4 different layouts available. Easy mounting to heat sink.

Features

1 x 180 W / 2 x 70 W / 3 x 40 W operating power
Tolerance range ±1 % to ±10 %
Ohmic range 1 Ω to 1 MΩ (higher value on request)
Temperature coefficient ±250 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Motor Drives & Controls
Power Supplies
Control Devices
Telecommunications
Robotics
Medical
Regen Energy
Traction
Welding
Electric Vehicle

Downloads

Product Data Sheet VHP

Series HPS 150

150 W power resistor - only configuration 1 possible. Easy mounting on heat sink.

Features

150 W operating power
Tolerance range ±1 % to ±10 %
Ohmic range 1 Ω to 1 MΩ (other values on request)
Temperature coefficient ±250 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Motor Drives & Controls
Power Supplies
Control Devices
Telecommunications
Robotics
Medical
Regen Energy
Traction
Welding
Electric Vehicle

Downloads

Product Data Sheet HPS 150

Series HXP 200 SOT-227 Housing

200 W resistor in "ISOTOP" power device. 5 different layouts available. Easy mounting to heat sink.

Features

1 x 200 W / 2 x 80 W / 3 x 45 W operating power
Tolerance range ±1 % to ±10 %
Ohmic range 0.1 Ω to 1 MΩ
Temperature coefficient >1R ±250 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
AEC-Q200 compliant

Typical applications

Motor Drives & Controls
Power Supplies
Control Devices
Telecommunications
Robotics
Medical
Regen Energy
Traction
Welding
Electric Vehicle

Downloads

Product Data Sheet HXP 200 SOT-227 Housing

Image shows power resistor part Series HXP

Series HXP-600

600 W resistor at 85°C bottom case. 5 different layouts available.

Features

1 x 600 W / 2 x 240 W / 3 x 135 W operating power
Tolerance range ±5 % to ±10 %
Ohmic range 0.15 Ω to 5 KΩ (higher values on request)
Temperature coefficient > 1R ±150 ppm/°C
Non-inductive design
ROHS compliant

Typical applications

Speed drives
Power supplies
Control devices
Robotics
Motor control

Downloads

Product Data Sheet HXP-600

Ultra-High-Power-Resistors

up to 2.000W

Series UXP^®-350_350 W
Series UXP^®-600_600 W
Series UXP^®-800_800 W
Series UXP^®-2000_2000 W
Series UPT^®-400_400 W
Series UPT^®-600_600 W
Series UPT^®-800_800 W
Series UXM-400_400 W
Series ULX^®-600_600 W
Series ULX^®-800_800 W
Series HXP-600_600 W
Series 969 W / W-S / W-L_up to 1700 W

Series UXP^®-350

To replace UXP^®-300 resistor. 350 W resistors. Easy mounting on heat sink.

Features

350 W operating power
Tolerance range ±5 % to ±10 % (tighter on request)
Ohmic range 0.1 Ω to 1M Ω (higher values on request)
Temperature coefficient ±150 ppm/°C to ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance
UL Certified

Typical applications

Speed drives
Power supplies
Control devices
Robotics
Motor control

Downloads

Product Data Sheet UXP®-350

Series UXP^®-600

600 W resistor. Easy mounting on heat sink.

Features

600 W operating power
Tolerance range ±5 % to ±10 % (tighter on request)
Ohmic range 0.1 Ω to 1.5 MΩ (higher values on request)
Temperature coefficient ±150 ppm/°C to ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance

Typical applications

Speed drives
Power supplies
Control devices
Robotics
Motor control

Downloads

Product Data Sheet UXP®-600

Series UXP^®-800

800 W resistor. Easy mounting on heat sink.

Features

800 W operating power
Tolerance range ±5 % to ±10 % (tighter on request)
Ohmic range 0.1 Ω to 1 MΩ (higher values on request)
Temperature coefficient ±150 ppm/°C to ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance
UL Certified

Typical applications

Speed drives
Power supplies
Control devices
Robotics
Motor control

Downloads

Product Data Sheet UXP®-800

Series UXP^®-2000

2000 W resistor at 125°C bottom case

Features

2000 W operating power
Tolerance range ±5 % to ±10 %
Ohmic range 0.15 Ω to 6 KΩ (higher values on request)
Temperature coefficient ±150 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge Performance

Typical applications

Speed drives
Power supplies
Control devices
Robotics
Motor control

Downloads

Product Data Sheet UXP®-2000

Series UPT^®-400

400 W resistor. Easy mounting on heat sink.

Features

400 W operating power
Tolerance range ±5 % to ±10 % (tighter tolerances on request)
Ohmic range 0.5 Ω to 1 MΩ
Temperature coefficient ±150 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance
UL Certified

Typical applications

Motor Drives & Controls
Power supplies
Robotics
Traction
Electric Vehicle
Medical
Welding
Regen Energy
Frequency Converters

Downloads

Product Data Sheet UPT®-400

Series UPT^®-600

600 W resistor. 6 different layouts available. Easy mounting on heat sink.

Features

1 x 600 W / 2 x 250 W / 3 x 120 W acc. configurations operating power
Tolerance range ±5 % to ±10 % (tighter tolerances on request)
Ohmic range 0.1 Ω to 1.5 MΩ (higher value on request)
Temperature coefficient ±150 ppm/°C to ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance
UL Certified

Typical applications

Motor Drives & Controls
Power supplies
Robotics
Traction
Electric Vehicle
Medical
Welding
Regen Energy
Frequency Converters

Downloads

Product Data Sheet UPT®-600

Series UPT^®-800

800 W resistor. 6 different layouts available. Easy mounting on heat sink.

Features

1 x 800 W / 2 x 300 W / 3 x 150 W acc. configurations operating power
Tolerance range ±5 % to ±10 % (tighter tolerances on request)
Ohmic range 0.1 Ω to 1 MΩ (higher value on request)
Temperature coefficient ±150 ppm/°C to ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance

Typical applications

Motor Drives & Controls
Power supplies
Robotics
Traction
Electric Vehicle
Medical
Welding
Regen Energy
Frequency Converters

Downloads

Product Data Sheet UPT®-800

Series UXM-400

400 W resistor. High pulse load resistor.

Features

400 W operating power
Tolerance range ±5 % to ±10 % (tighter tolerances on request)
Ohmic range 0.1 Ω to 10 Ω
Temperature coefficient ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance

Typical applications

Motor Drives & Controls
Power supplies
Robotics
Traction
Electric Vehicle
Medical
Welding
Frequency Converters

Downloads

Product Data Sheet UXM-400

Series ULX^®-600

600 W resistor. Very low component height. 6 different layouts available.

Features

1 x 600 W / 2 x 250 W / 3 x 120 W acc. configurations operating power
Tolerance range ±5 % to ±10 % (tighter tolerances on request)
Ohmic range 0.1 Ω to 1.5 MΩ (higher values on request)
Temperature coefficient ±150 ppm/°C to ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance

Typical applications

Motor Drives & Controls
Power supplies
Robotics
Traction
Electric Vehicle
Medical
Welding
Regen Energy
Frequency Converters

Downloads

Product Data Sheet ULX®-600

Series ULX^®-800

800 W resistor. Very low component height. 6 different layouts available.

Features

1 x 800 W / 2 x 300 W / 3 x 150 W acc. configurations operating power
Tolerance range ±5 % to ±10 % (tighter tolerances on request)
Ohmic range 0.1 Ω to 1 MΩ (higher values on request)
Temperature coefficient ±150 ppm/°C to ±500 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform
High insulation & Partial discharge performance
UL Certified

Typical applications

Motor Drives & Controls
Power supplies
Robotics
Traction
Electric Vehicle
Medical
Welding
Regen Energy
Frequency Converters

Downloads

Product Data Sheet ULX®-800

Series HXP-600

600 W resistor at 85°C bottom case. 5 different layouts available.

Features

1 x 600 W / 2 x 240 W / 3 x 135 W operating power
Tolerance range ±5 % to ±10 %
Ohmic range 0.15 Ω to 5 KΩ (higher values on request)
Temperature coefficient > 1R ±150 ppm/°C
Non-inductive design
ROHS compliant

Typical applications

Speed drives
Power supplies
Control devices
Robotics
Motor control

Downloads

Product Data Sheet HXP-600

MTX 969 Widerstände Water-cooled High Power resistors

Series MTX 969 W / W-S / W-L

High-Power water-cooled single resistors up to 1,700 W.

Features

Up to 1700 W operating power
Up to 10 kV operating voltage
Tolerance range ±10 % to ±5 %
Ohmic range 0.5 Ω to 10 MΩ
Temperature coefficient ±100 ppm/°C ≥ 10 Ω (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet MTX 969 W / W-S / W-L

High Voltage
Cylindrical Resistors

up to 96kV

Series SGT_up to 48 kV
Series SGP / OGP_up to 48 kV
Serie SSP / OSP_up to 40 W
Series OSX / SSX / SOX_up to 60 kV
Series MTX 968_up to 54 kV
Series MTX 969_up to 96 kV
Series 969 W_up to 10 kV
Series MTX 2000_up to 80 kV & 50 W

Series SGT

TCR of ±25 ppm/°C combined with wide ohmic range (100 KΩ to 1 GΩ) and precision tolerances
(±0.1 % to ±1 %).

Features

Up to 48 kV DC operating voltage
Tolerance range ±0.1 % to ±1 %
Ohmic range 100 KΩ to 1 GΩ
Temperature coefficient ±25 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet SGT

SGP & OGP High Voltage Cylindrical Resistors

Series SGP / OGP

TCR of ±80 ppm/°C combined with wide ohmic range (100 Ω to 10 GΩ) and precision tolerances (±0.1 % to ±10 %).

Features

Up to 48 kV operating voltage
Tolerance range ±0.1 % to ±10 %
Ohmic range 100 KΩ to 10 GΩ
Temperature coefficient ±80 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet SGP / OGP

SSP & OSP High Voltage Cylindrical Resistors

Series SSP / OSP

Standard TCR of ±50 ppm/°C and wide ohmic range (0.1 Ω to 30 MΩ).

Features

Up to 40 W operating power
Tolerance range ±0.1 % to ±10 %
Ohmic range 0.1 Ω to 30 MΩ
Temperature coefficient ±50 ppm/°C ≥ 10 Ω (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet SSP / OSP

OSX & SSX & SOX High Voltage Cylindrical Resistors

Series OSX / SSX / SOX

Standard TCR of ±100 ppm/°C and wide ohmic range (100 Ω to 10 GΩ).

Features

Up to 60 kV operating voltage
Tolerance range ±0.1 % to ±10 %
Ohmic range 100 Ω to 50 GΩ (higher values on special request)
Temperature coefficient ±100 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet OSX / SSX / SOX

MTX 968 High Voltage Cylindrical Resistors

Series MTX 968

High-voltage resistors with wide ohmice range (400 Ω to 100 GΩ).

Features

Up to 54 kV operating voltage
Tolerance range ±0.1 % to ±10 %
Ohmic range 400 Ω to 30 GΩ (depending on model no.)
Temperature coefficient ±15 ppm/°C to ±200 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet MTX 968

MTX 969 High Voltage Cylindrical Resistors

Series MTX 969

High-voltage resistors up to 96 kV and 105 W.

Features

Up to 96 kV operating voltage
Tolerance range ±0.1 % to ±10 %
Ohmic range 2 Ω to 25 GΩ (depending on model no.)
Temperature coefficient ±10ppm/°C to ±200ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet MTX 969

MTX 969 W & W-S & W-L Water-cooled High Power resistors

Series MTX 969 W

High-Power water-cooled single resistors and up to 10 kV operating voltage.

Features

Up to 10 kV operating voltage
Up to 1700 W operating power
Tolerance range ±5 % to ±10 %
Ohmic range 0.5 Ω to 10 MΩ
Temperature coefficient ±100 ppm/°C ≥ 10 Ω (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Energy

Downloads

Product Data Sheet MTX 969 W

Series MTX 2000

High-voltage resistor up to 50 W.

Features

Up to 50 W operating power
Tolerance range ±1 % to ±0.1 %
Ohmic range up to 3 GΩ
Absolute temperature coefficient ±50 ppm/°C to ±15 ppm/°C
Ratio temperature coefficient ±25 ppm/°C to 10 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Electrostatic
Smart Grid Sensing / Metering
X-Ray
Motor Controls
Instrumentation

Downloads

Product Data Sheet MTX 2000

High Voltage Flat Resistors

up to 35kV

Series FSX / FEX / FBX_up to 32 kV
Series FPX / FLX_up to 16.5 kV & 7.5 W
Series MTX 967_up to 35 kV

Series FBX / FEX / FSX

TCR of ±80 ppm/°C combined with wide ohmic range (200 Ω to 2 GΩ) and precision tolerances (±0.5 % to ±10 %).

Features

Up to 32 kV operating voltage
Tolerance range ±0.5 % to ±10 % (down to ±0.1 % on request)
Ohmic range 200 Ω to 2 GΩ (higher values on special request)
Temperature coefficient ±80 ppm/°C ≤ 100 MΩ
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Electrostatic
Smart Grid Sensing / Metering
X-Ray
Motor Controls
Instrumentation

Downloads

Product Data Sheet FBX / FEX / FSX

Series FPX / FLX

TCR of ±100 ppm/°C combined with wide ohmic range (10 Ω to 2 GΩ) and precision tolerances (±0.5 % to ±10 %).

Features

Up to 22 kV operating voltage
Up to 7.5 W operating power
Tolerance range ±0.5 % to ±10 %
Ohmic range 200 Ω to 2 GΩ
Temperature coefficient ±100 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Electrostatic
Smart Grid Sensing / Metering
X-Ray
Motor Controls
Instrumentation

Downloads

Product Data Sheet FPX / FLX

Series MTX 967

Flat style resistor ±15 ppm/°C to ±200 ppm/°C. Different coatings like silicone, glass or polyimide available.

Features

Up to 35 kV operating voltage
Tolerance range ±0.1 % to ±10 %
Ohmic range 10 Ω to 30 GΩ (depending on model no.)
Temperature coefficient ±15 ppm/°C to ±200 ppm/°C (lower TCR on request)
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Electrostatic
Smart Grid Sensing / Metering
X-Ray
Motor Controls
Instrumentation

Downloads

Product Data Sheet MTX 967

Voltage Dividers and
Network Resistors

up to 80kV

Series HVT_up to 20 kV
Series MTX 1000_up to 32 kV
Series MTX 2000_up to 80 kV
Series 1776-X

Series HVT

Flat style HV network packages and up to 20 kV operating voltage.

Features

Up to 20 kV operating voltage
Absolute tolerance ±1 %
Ratio tolerance down to ±0.1 %
Ohmic range: 100 MΩ and 200 MΩ (other values on request)
Absolute temperature coefficient ±100 ppm/°C, lower on request
Ratio temperature coefficient ±25 ppm/°C (10 ppm/°C on request)
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Test Measurement
Smart Grid Sensing / Metering
Instrumentation

Downloads

Product Data Sheet HVT

Series MTX 1000

Flat style HV network packages and up to 32 kV operating voltage.

Features

Up to 32 kV operating voltage
Absolute tolerance range ±0.1 % to ±1 %
Ohmic range on request
Absolute temperature coefficient ±15 ppm/°C to ±50 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Test Measurement
Smart Grid Sensing / Metering
Instrumentation

Downloads

Product Data Sheet MTX 1000

Series MTX 2000

High-voltage resistor up to 80 kV operating voltage

Features

Up to 80 kV operating voltage
Up to 50 W operating power
Tolerance range ±1 % to ±0.1 %
Ohmic range up to 3 GΩ
Absolute temperature coefficient ±50 ppm/°C to ±15 ppm/°C
Ratio temperature coefficient ±25 ppm/°C to 10 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Electrostatic
Smart Grid Sensing / Metering
X-Ray
Motor Controls
Instrumentation

Downloads

Product Data Sheet MTX 2000

Series 1776-X

Precision decade dividers / networks. High number of different electrical characteristics available.

Features

Absolute tolerance range ±0.5 % to ±0.1 %
Ratio tolerance range ±0.25 % to ±0.05 %
Ohmic range on request
Absolute temperature coefficient ±25 ppm/°C to ±50 ppm/°C
Ratio temperature coefficient ±10 ppm/°C to ±50 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

HV Measurement
Power Supplies
Medical
Test Measurement
Smart Grid Sensing / Metering
Instrumentation

Downloads

Product Data Sheet 1776-X

Shunts

up to 100W

Series PCS_up to 100 W

Series PCS

3 W / 60 W / 100 W current sense resistors. 4-terminal Kelvin Connection.

Features

3 W / 60 W / 100 W operating power
Tolerance range ±5 % to ±1 % (tighter on request)
Ohmic range 0.5 mΩ to 1 Ω
Temperature coefficient ≤ ±60 ppm/°C (up to ±500 ppm/°C depending on ohmic value)
Non-Inductive design
ROHS conform

Typical applications

Motor Controls
Test Measurement
Power Supplies
Instrumentation

Downloads

Product Data Sheet PCS

High Precision
Metal Film Resistors

TCR down to 2ppm

Series UPR / UPSC
Series NE / EE

Series UPR / UPSC

Radial resistors. Extremely precise.

Features

High precision ohmic values
Low temperature coefficient precision resistors
Long-term stability
Ohmic range for UPSC 100 Ω to 1 MΩ
Ohmic range for UPR 10 Ω to 255 KΩ
Temperature coefficient ±3 ppm/°C to ±15 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

Power supplies
HV measurement
Instrumentation

Downloads

Product Data Sheet UPR / UPSC

Series NE / EE

Precision metal film resistors. Molded style.

Features

Up to 1.50 W operating power for NE
Up to 350 V operating voltage for EE
Tolerance range ±5 % to ±0.05 %
Ohmic range up to 0.025 Ω to 15 MΩ
Temperature coefficient ±5 ppm/°C to ±50 ppm/°C
Non-Inductive design
ROHS conform

Typical applications

Power supplies
HV measurement
Instrumentation

Downloads

Product Data Sheet NE / EE

Ultra-High-Precision Resistors

TCR down to 5ppm

Series SHP

Ultra-stable High-Voltage Resistor, overall stability ±5 ppm/°C from +25 to 65°C (including TCR & VCR)

Features

10 kV operating voltage
Tolerance range ± 1 % (lower on request)
Ohmic range 100 MΩ to 250 MΩ (other values on request)
Overall stability ± 5ppm/°C from +25 to 65°C (including TCR and VCR)
Non-Inductive design
RoHS-konform

Typical applications

Power Supplies
Medical
Motor Drives & Controls
Electrostatic
Smart Grid Sensing / Metering
Converters
X-Ray
Regen Engergy

Downloads

Product Data Sheet SHP

Custom designed

Carbon Disc Resistors

Series CSR

Series CSR

High energy resistor, PCB mounting

Features

up to 6.5 W operating power
Tolerance range ±20 % standard (±10 % on request)
Ohmic range 1 Ω to 700 Ω
Temperature coefficient -500 ppm/°C to -1500 ppm/°C

Typical applications

Electrical transmission
Traction
Pulse power supply
Inductive heating

Downloads

Product Data Sheet CSR

ABOUT EBG

Elektronische Bauelemente GmbH (EBG) is one of the leading international manufacturers of resistors for high-performance electronics. These technologically demanding components contribute to the safe and efficient conversion and transmission of energy. Among other things, EBG’s resistors are used in electric power trains of high-speed trains, electrical cars, frequency converters in wind turbines, aerospace applications or HVDC power transmission systems. The company has been part of the Miba Group since 2010.

Contactus

Products

Series LXP-18 TO-220

18 W Thick Film Power Resistors for high-frequency and pulse-loading applications. Single screw mounting.

Downloads

Series LXP-20 TO-220

20 W Thick Film Power Resistors for high-frequency and pulse-loading applications. No mounting hole (snap-on). Heat sink required.

Downloads

Series LXP-100 B TO-247

100 W Thick Film Power Resistors for high-frequency and pulse-loading applications. Version B for enforced mechanical stability.

Downloads

Series MXP 35 TO-220

35 W Thick Film Power Resistors for high-frequency and pulse-loading applications. Single screw mounting.

Downloads

Series MSP 35 SMD TO-220

35 W Thick Film Power Resistors for surface mount including metal tab. MHP 35 for high temperature soldering!

Downloads

Series AXP-50

50 W resistors with up to 4 wire terminals.

Downloads

Series AXP-100 B

100 W resistors with 4 wire terminals, Version B for enforced mechanical stability.

Downloads

Series AXM

100 W low ohm pulse power resistor - only configuration 1 possible

Downloads

Series GXP 120 SOT-227 Housing

120 W power resistor in "ISOTOP" power device. 6 different layouts available. Mounting to heat sink is required.

Downloads

Series HPP 150

150 W power resistor according to VDE 0160 and UL 94-V0. 4 different layouts available. Easy mounting to heat sink.

Downloads

Series VHP

180 W power resistor according to VDE 0160 and UL 94-V0. 4 different layouts available. Easy mounting to heat sink.

Downloads

Series HPS 150

150 W power resistor - only configuration 1 possible. Easy mounting on heat sink.

Downloads

Series HXP 200 SOT-227 Housing

200 W resistor in "ISOTOP" power device. 5 different layouts available. Easy mounting to heat sink.

Downloads

Series HXP-600

600 W resistor at 85°C bottom case. 5 different layouts available.

Downloads

Series UXP®-350

To replace UXP®-300 resistor. 350 W resistors. Easy mounting on heat sink.

Downloads

Series UXP®-600

600 W resistor. Easy mounting on heat sink.

Downloads

Series UXP®-800

800 W resistor. Easy mounting on heat sink.

Downloads

Series UXP®-2000

2000 W resistor at 125°C bottom case

Downloads

Series UPT®-400

400 W resistor. Easy mounting on heat sink.

Downloads

Series UPT®-600

600 W resistor. 6 different layouts available. Easy mounting on heat sink.

Downloads

Series UPT®-800

800 W resistor. 6 different layouts available. Easy mounting on heat sink.

Downloads

Series UXM-400

400 W resistor. High pulse load resistor.

Downloads

Series ULX®-600

600 W resistor. Very low component height. 6 different layouts available.

Downloads

Series ULX®-800

800 W resistor. Very low component height. 6 different layouts available.

Downloads

Series HXP-600

600 W resistor at 85°C bottom case. 5 different layouts available.

Downloads

Series MTX 969 W / W-S / W-L

High-Power water-cooled single resistors up to 1,700 W.

Downloads

Contact
us

Series UXP^®-350

To replace UXP^®-300 resistor. 350 W resistors. Easy mounting on heat sink.

Series UXP^®-600

Series UXP^®-800

Series UXP^®-2000

Series UPT^®-400

Series UPT^®-600

Series UPT^®-800

Series ULX^®-600

Series ULX^®-800

TCR of ±25 ppm/°C combined with wide ohmic range (100 KΩ to 1 GΩ) and precision tolerances
(±0.1 % to ±1 %).
